Smoke Vent Rooflight AOV - Mardome Trade

Buy now pay later with Klarna

Quantity

19 sold in last 11 hours.

This Item is Made To Order

Maximum quantity available reached.
0 people are viewing this now.

Buy Now, Pay Later at Checkout – 0% INTEREST! Manufactured By Brett Martin

High thermal performance
Clip-on features - fast to fit

Warranty

No visible fixings
Simple neat design

Easy fit

Made to Measure

Key Features

  • UK mainland delivery
  • Stock sizes fast delivery
  • Complies with BS EN 12101-2
  • Great U values
  • Available in Double & Triple Skins
  • Wind deflectors available to improve aerodynamic performance
  • A range of finishes available

Click Tabs Below To Reveal More Information

Mardome SV Trade Smoke Vent Rooflights offer a reliable, contemporary and robust smoke system which maximises natural light entering the building.

Brett Martin Daylight Systems Mardome Trade Smoke Vents are individual polycarbonate dome rooflights intended for installation on flat roofs of all modern building types to provide natural smoke and heat exhaust ventilation and comfort ventilation. Mardome Trade Smoke Vents are designed and manufactured in the UK. These products are fully tested and certified in accordance with EN12101-2 : 2003.

The Mardome Trade Smoke Vent Skylight is the ideal skylight with which to build a robust smoke exhaust system in commercial properties. Compatible with a number of different control panels from the same manufacturer, each unit is fitted with an electrically operated hinge, allowing it to be opened and closed remotely, or automatically in the event of a fire. In order to take advantage of this automated functionality, each skylight should be connected to a compatible control panel, along with smoke detectors that are designed to trigger the system should a fire break out.

Mardome Trade Smoke Vent Skylight: Key Benefits

The Mardome Trade Smoke Vent Skylight offers a number of benefits that make it worthy of serious consideration for commercial smoke and heat exhaust applications:

  • Excellent Energy Efficiency Performance – With impressive U-Values, this skylight is a great choice for buildings in which energy efficiency is a priority.
  • Fully Certified Smoke Vents – Because it has been certified to CE EN12101-2, this skylight is suitable for installation in all types of commercial and residential properties across the UK. This makes it an excellent option for companies that wish to avoid compliance issues with their smoke exhaust systems.
  • Choice of Glazing – When you order a new smoke vent skylight from us, you can specify whether you would like it to be fitted with double or triple glazing and you can also choose the type of glazing: clear, patterned or opal.
  • Concealed Fixings – The Mardome Trade Smoke Vent was designed with concealed fixings, to make it more difficult to tamper with. For properties where security is an important consideration, these skylights are therefore a very popular choice.
  • Manual or Automatic Operation – The Mardome Smoke Vent Skylight can be triggered automatically, via a control panel with smoke detectors, or manually, via a local override switch. In either case, the skylight will respond to the trigger and open as directed.
  • Dual Functionality – In addition to providing the smoke exhaust functionality you need for your fire safety systems, the Mardome Smoke Vent will allow more daylight into your building, thanks to the high-quality double or triple-skin polycarbonate glazing with which it is fitted as standard.

If you require more information about these skylights, please see the other tabs. You are also more than welcome to get in touch with us should you require personal assistance from one of our consultants.

Please see fitting instructions below and downloadable PDF link at the bottom of this page and product data sheet..

Range of Sizes

Available in sizes from 1050x1050mm up to 1800x1800mm which stagger up in 150mm increments. If your size doesn’t appear here, we will be happy to assist with any query.

Measuring Guide for fitting to builders upstand

Measure internal AND external builders upstand

Acceptable tolerance:

 Internal builders upstand = (dome size - 150mm) +20/-0

 External builders upstand = dome size +40/-20mm

If you are installing on your own upstand, the upstand height should be 200mm. For example, on our website is a drop-down menu for you to order from, ff you choose 1050x1050mm this would mean your structural opening would be 900x900mm. The builders upstand should be 75mm in width.

Measuring Guide for domes with PVC kerb

Measure internal roof opening

Acceptable tolerance = dome size +20/-30mm

If you purchase with an upstand then the size you order from our website’s drop-down menu will be the structural opening measurement (shown in the diagram above in red). Please note this does not apply if you fit on your own upstand.

Glazing Information:

Centre pane U-value is a measure of the thermal efficiency of the glazing type.

Ud-value is a measure of the thermal efficiency of the whole rooflight (calculated in accordance with NARM Technical Document NTD2).

Part L Building Regulations require a U-value of at least 2.2W/m2K: Brett Martin Daylight Systems recommend the use of at least triple skin rooflights in all applications

Tint:

The table below shows Reflex polycarbonate rooflight light’s transmission properties:

Clear - high visibility

Maximum transmission of light

Elevated transparency of vision of everything through the dome

Opal - diffused light and solar control

Ties privacy with top levels of diffused light generation

Prevents solar glare and minimises solar heat gain

Reduces sight of all objects through the dome

Patterned - privacy

Partners increased levels of light transmission with privacy

Diffused light of day

Impairs the optical production of materials through the dome

Bronze - solar control

Restricts solar glare and heat gain

Offers a lower transmission of light

Additional Options

To enquire about additional options please call or email us.

Fire and Comfort Ventilation Control Panel - EN12101-10 certified.

Fireman's Priority Switch with break glass to open/close Smoke Vent without influencing the alarm.

Fire Switch with break glass to open Smoke Vent and activate the alarm.

Smoke Detector

Warranty:

20 year manufacturers warranty.

FAQs

-

These dual-purpose smoke vent roof lanterns allow more daylight to penetrate into rooms and function as an effective active fire protection system too. Designed to open in the event of a fire, the opening mechanisms may be triggered manually or automatically, depending on the design of the system in which the lanterns are installed. Available with either double or triple layer polycarbonate domes, they are also very thermally efficient, making them a good choice for both residential and commercial buildings in the United Kingdom. If you are looking for roof lanterns to form part of a fire protection system and you want to make sure they won’t compromise the existing insulation in your property, Mardome smoke vents are the perfect solution.

Fully Certified Smoke Vent Roof Lanterns

Certified to CE EN12101-2, all units are assembled and tested at the factory to ensure full compliance with this standard. As fully certified smoke vents that have been designed and manufactured in accordance with the Building Regulations on Fire Safety, they are suitable for installation in all types of residential and commercial properties, including rental properties and properties with communal spaces.

Configuring Manual or Automatic Operation

The control panel supplied with our smoke vent roof lanterns may be triggered manually with a local override switch. Alternatively, the control panel may be integrated into an existing fire alarm or smoke detection system for automatic operation. In either case, the vents will open immediately to provide effective smoke and heat extraction in the event of a fire. Please note, the control panel has a battery backup power supply included, ensuring that the vents will open even if there is no mains electricity.

Your Choice of Glazing

As our smoke vent roof lanterns are made to order, you can choose which type of glazing you would like to have installed in them. The options include double or triple layers of either clear, patterned or opal polycarbonate sheeting.

Secure Smoke Vents

Some property owners are hesitant to install smoke vents in case the security of their buildings is compromised. However, these vents are fitted to the roof with fixings that are concealed inside security caps, ensuring they are not an easy target for opportune thieves who are operating in your area.

What glazing material is this smoke vent skylight?

The smoke vent AOV rooflight is polycarbonate material and this is due to this material being lightweight and more impact resistant to maintain the opening and closing function.

What extra option do I need?

We sell an array of optional extras with our smoke vent AOV roof light. This means that customers can select which extra options they require. The most common option is our control panel 5A however we advise customers check in accordance with their specification requirements to ensure the correct extra option is ordered for the project as these are made to order.

Can I add more than one additional extra?

Customers can opt to add more than just one optional extra as your project may have requirements for more. This would be processed by emailing or contacting Rooflights & Roof Lanterns and we would arrange payment along with add the additional extra items to your order.

If you are ready to purchase, you can select your preferred options and place your order on our website now. If you need any assistance, please call or email us.

This product can be delivered within 7-10 working days for most sizes.

You will need to ensure an appropriate person is designated and on site to offload the product out of the vehicle when the driver arrives.

We recommend arranging equipment and installation after the item has been delivered. Please Note lead time to Ireland will be longer than the standard lead time above.
